Forklift Rotating Bale Clamp

Material handling equipment lifting equipment bale clamp

Ilovalar

-Bale clamp efficiently and economically handle nearly any type of baled products including cotton, wool, synthetic, textile bales, corrugated, newsprint, rag, hay, metal and other scrap bales.

-High efficiency and economy to handle in without work platform condition.

Features & Advantages

-Proven durable T-beam arm aluminum frame construction.

-Proven durable T-beam arm aluminum frame construction.
-Superior arm-slide bearing for extended service life.
-Ribs provide secure grip and give driver good tip handling and bale spinning capabilities.
-Regenerative hydraulic valving for optimal arm speed.
-Excellent driver visibility.

forklift Bale clamp
forklift rotating bale clamp

An important component of a product configuration

Hydraulic systems: the main control valve in the load to maintain valve adopts imported products; seals are imported products; high-pressure hose with cone seal, high-performance hose.

Structural parts: the left and right plates with Q460 high-performance steel plates, shaped by the overall pressure and correction.

Mechanical performance: Built-in lateral feature, you can also achieve clamping / opening and lateral function and good vision; additional oil line can meet the requirements of the two groups.

Application: can be effective and economic handling almost any form of software packages, such as cotton, wool, textiles, corrugated sheets, white paper, rags, hay, and other industrial debris.

Katalog Buyurtma raqami	Imkoniyatlar @load center (Kg@mm)	O'rnatish Sinf	Ochilish Qator (mm)	Available Forklift	Arm Height (mm)	Qurol Length (mm)	Frame width (mm)	Overall height (mm)	Og'irligi (Kg)	Samarali Qalinligi (mm)
RJ19RT-A1	800@500	Ⅱ	445-1670	1-2.5t	420	996	1040	796	580	198
RJ25RT-A1	2500@500	Ⅱ	600-1880	2-2.5t	460	1200	1010	769	750	259
RJ30RT-B1	2700@500	Ⅲ	560-1850	3-4,5t	460	1200	1010	769	750	259

Eslatma

1, haqiqiy yuk mashinasi / yuk ko'tarish qobiliyati forkliftdan olingan keng qamrovli zavoddir.
2, this is a matching increase in group 2 required additional forklifts require asphalt.

Videolar

Tez ma'lumotlar

Kelib chiqishi joyi: Fujian, Xitoy (materik)
Brand Name: HUAMAI forklift rotating bale clamp
Feature: Side shifting or rotating
Material: High strengthen steel
Certificates: ISO 9001:2000 & CE
Warranty 12 months
Drive: Hydraulic control
Capacity: 2-6.5 tons
Mounting class: II-IV
